Overview
The Omron R88M-W1K315F-S2 is a powerful AC servo motor of the 1.3 kW class and part of the R88M-W series. This series was designed for high continuous load, precise speed control and use in demanding CNC and industrial systems. Due to the robust torque behavior and compatibility with Omron W servo packs, the motor is ideal for machine tools, powerful axes and automation with high reliability.
Model designation
- R88M = Omron AC servo motor series
- W = W series, compatible with R88D-W servo packs
- 1K3 = Power range approx. 1.3 kW
- 15F = Rated speed/rated current and length designation
- S2 = Variant with special encoder/connection configuration
Technical Data
| Feature | Value |
|---|
| Rated power | 1300 W |
| Rated voltage | 200 V |
| Rated current | 5.4 A |
| Rated torque | 8.34 N·m |
| Rated speed | 1500 r/min |
| Type | 3-phase synchronous servo motor |
| Insulation | Class F |
| Continuous operation | CONT. 40V InS.F |
| Encoder | UTSIH-B17CC (Incremental, high resolution) |
| Compatible Drive | R88D-W series (e.g. WT series, WD series) |
| Brake | none specified (motor without holding brake) |
Connections & Interfaces
- U / V / W: Three-phase motor power connection
- Encoder connection UTSIH-B17CC: High-resolution incremental encoder, Omron-type circular connector
- PE: Protective earth on the housing
- Connector system: Omron Heavy-Duty connector (motor/encoder separate)
Control board / Assemblies
- 3-phase stator winding
- Permanent magnet rotor
- Encoder UTSIH-B17CC (incremental encoder, 17-bit class)
- Temperature sensor in the stator
- Double ball bearing front/rear
- Electrical connection modulation (terminal block)
Alarms & Troubleshooting (Top 10 – typical errors on the compatible R88D-W servopack)
| Code | Bezeichnung | Typischer Befund | Prüfung | Abhilfe |
|---|
| A.16 / A.40 | Encoder Error | Feedback fehlt | CN2, Leitungen, Steckverbinder | Encoder/Kabel ersetzen |
| A.41 | Phase Error | Phasen falsch angeschlossen | U/V/W prüfen | richtig anklemmen |
| A.10 | Overcurrent | mechanical blockage | Motor manuell drehen | Mechanik prüfen |
| A.72 | Überlast | konstante hohe Last | Lastprofil prüfen | Last reduzieren |
| A.24 | Ground Fault | Wicklung gegen Erde | Isolationsmessung | Motor/Kabel ersetzen |
| A.30 | Regeneration Error | Bremsenergie zu hoch | Bremswiderstand messen | größeren RB einsetzen |
| A.20 | Communication Error | Encoder-Signal instabil | Durchgang der Leitungen | Kabel ersetzen |
| A.50 | Motor Overheat | Fühler löst aus | Temperatur prüfen | Kühlung/Last prüfen |
| A.31 | Overspeed | unplausibles Feedback | Encoder-Z-Spur prüfen | Encoder/Kabel ersetzen |
| A.32 | Overcurrent (Drive) | Endstufe überlastet | U/V/W getrennt testen | Drive prüfen |
Typical applications
- Machine tools with high mass inertia loads
- Turning, milling, portal and vertical axes
- Automated lifting and transport systems
- Presses, axis controllers, feed systems
- Industrial handling and robotics modules
Service notes
- Regularly monitor noise and temperature behavior
- Check encoder connectors and cables for kinks and oil exposure
- Do not perform insulation measurement on the connected motor
- Observe bearing condition during operation (vibration, noise)
- Keep the environment clean (avoid dust, oil, coolant)
Repair description
- Incoming inspection: visual inspection, insulation measurement, winding resistance, encoder line test
- Disassembly & cleaning: open motor, clean stator/rotor, expose bearings
- Analysis: Inspection of bearings, windings, temperature sensors and encoder signal quality
- Repair: Replacement of defective bearings, cleaning of the interior, replacement of the UTSIH-B17CC encoder if necessary
- Testing & load test: functional test on the R88D-W servopack, control of current consumption, smooth running, torque behavior
- Endurance test & conclusion: continuous operation under rated torque, thermal stability test, create final report
