Overview
The Mitsubishi MDS-DH2-V2-4020 is a modern and proven servo drive of the 400V class. Developed for maximum precision and efficiency in the CNC sector, this drive module impresses with its robust design, service-friendly construction and excellent performance stability. Ideal for use in multi-axis machining centers and machine tools.
Model designation
- MDS = Mitsubishi Drive System
- DH2 = Series DH2 (second generation of high-performance drives)
- V2 = Servo amplifier for axis drives
- 4020 = Power rating (4.0 kW, 200 internal class)
Technical Data
| Feature | Value |
|---|
| Rated power | 2.0 / 1.0 kW |
| Input voltage | DC 513–648 V |
| Input current | 4.7 A |
| Control power supply | 1-phase 380–480 V, 0.1 A |
| Output voltage | 3-phase 456 V, 0–240 Hz |
| Output current | 7.3 / 3.9 A |
| Protection class | IP20 |
| Year of manufacture | 2015 |
| Cooling | Forced ventilation |
| Weight/Dimensions | n/a |
Connections & Interfaces
- L1 / L2 / L3: Mains connection 3~ 400–480 V
- U / V / W: Motor outputs to servo axes
- CN1 / CN2 / CN3: Control and communication connections
- P / N / RB: DC link and braking resistor
- PE: Protective earth connection
- LED display / 7-segment: Status and error code display
Control board / Assemblies
| Name | Designation on board | Quantity |
|---|
| Control board | RM120B-22 ½K or BC868A097G51A | 1 |
| Power board | RM162C-V2 or BC868A010G52F | 1 |
| Power section | BKO-NC1207 H84 or A2-DH2-V2-2020 | 1 |
Alarms & Troubleshooting
| Code | Designation | Typical finding | Check | Remedy |
|---|
| 03 | Overcurrent | Short circuit or motor overload | Insulation test, phase measurement | Check motor and power section |
| 05 | Overvoltage | Overvoltage in the DC bus | Measure DC voltage | Check power supply, test braking resistor |
| 07 | Undervoltage | DC voltage too low | Measure intermediate circuit | Check power supply |
| 11 | Overheat | Temperature too high | Check fan, sensor | Clean fan and heat sink |
| 17 | Control power error | Control current missing | Check 24V/control voltage | Restore supply |
| 32 | Power module overcurrent | Overcurrent in the IPM | Measure output currents | Replace power section |
| 50 | Overload | Permanent overload | Current measurement, check load profile | Adjust axis parameters |
| 58 | Encoder fault | Encoder error | Check signal | Replace cable or encoder |
| 70 | Regeneration error | Regeneration problem | Check brake circuit | Check resistor and circuit |
| 79 | Communication error | Communication error | Check CN line | Replace cable, check EMC |
Typical Applications
- CNC machining centers
- Lathes and milling machines
- Multi-axis manufacturing systems
- High-precision positioning and linear drives
Service Notes
- Clean fans and cooling channels regularly
- Check and replace electrolytic capacitors preventively
- Regularly check the control board for solder joints and insulation condition
- Back up the parameters before each intervention
- Do not perform megger measurements on the installed device
- Regularly check the earthing for a firm fit
Repair description
- Input check: Visual inspection for contamination, burn marks and loose connectors. Measurement of the DC link voltage and insulation values.
- Disassembly & Cleaning: Removal of the boards and the fan, thorough cleaning of all cooling surfaces, renewal of the thermal paste.
- Analysis: Checking the control and power sections for typical errors such as overcurrent, defective sensors or communication errors.
- Repair: Replacement of damaged assemblies and critical components such as power modules, drivers or filter capacitors.
- Testing & Load test: Simulati
